6A 8a 72w 96w Desktop Power Supply , Ac To Dc Power Adapter Vi Efficiency

Product Categories
HK Anenerge Co., Limited
Contact Now

6A 8a 72w 96w Desktop Power Supply , Ac To Dc Power Adapter Vi Efficiency

  • 1
  • 2
  • 3

Brand Name : OEM/Anenerge

Model Number : AE-1200800

Certification : CE Rohs FCC UL GS CB

Place of Origin : shenzhen

MOQ : 1pcs

Price : 1-3usd/pcs

Payment Terms : D/P, T/T, Western Union,Paypal

Supply Ability : 100000pcs/month

Delivery Time : 3-5days

Packaging Details : Neutral white box packaging

Output : 12volt 8amp

Power : 96W

Efficiency : 85%

Packaging : Neutral white box

Plugs : EU US UK SAA

Certificates : CB UL CE GS TUV

Contact Now

6A 8a 72w 96w Desktop Power Supply , Ac To Dc Power Adapter Vi Efficiency

Specification:

1. Input : AC 100-240V 50/60HZ

2. Output: 12V 8A 96W

3. Plug option: AU EU UK US AUS CN

4. Inlet type: C6 C8 C14

5. AC/DC cable length: 1.2M/1.5M

6. Size:138*60*34mm

7. DC Jack size: 5.5*2.5mm or 5.5*2.1mm

8. MOQ: 500pcs

9. Package: white box+carton

10. Delivery:1-3 workdays for samples

11. Warranty: 3 years

12. Certification: UL/CUL CE CB FCC GS TUV PSE ROHS SAA KC

Input Characteristics Rated Voltage 100~240Vac
Variation Range 90-264Vac
Rated Frequency: 50/60Hz
Variation Frequency 47-63Hz
AC Current 1.8Amps max
AC Leakage Current 0.25mA

Output Characteristics

 12V 8A 96W
Ripple and Noise: 120mV p-p
Turn- on Delay Time 2Seconds Max.at 115Vac input and output Max.load
Rise time 40 mS Max.at 115Vac input and output Max load
Hold-up Time 5 mS Min.at 115Vac input and output Max.Load
Efficiency 80% Min, At 115/230Vac input voltag
Output Overshoot/ Undershoot 10% max
Protection over voltage protection: 120%min
over current protection: 120%min
Short-circuit protection: automatic recovery
Operation Temperature 0°C to 40°C
Environment Requirements Storage Temperature -20°C to +80°C
Relative Humidity 5%(0°C )~90%(40 °C)RH
Operating: IEC 721-3-3 3M3
Vibration Transportation: IEC 721-3-2 2M2
Axes,10 cycles per axis.

Dropping Packed

 1M for wall mount type and 760mm for desktop type as above described

Reliability Requirements

 Burn-in 2 hours under normal input and 80%rated load at 30°C ±10°C
MTBF Qualification at least 50,000 hours at 25°C
Mechanical Requirement Enclosure size: L138xW60xH34mm
Input Connector C14 C6 C8

Working Condition:

Operating Temperature: 0 ~ +40°C
Storage Temperature: -40 ~+80 °C
Operating Humidity: 10% ~ 90% RH Non-condensing
Humidity: 5% ~ 95% RH Non-condensing
Output noise and ripple:100mvpp
Output voltage adjustable rate:5%

Specification:

output voltage :12v
output current :8A
output power :96W
output short circuit to protect:less than 2w
output ripple and noisy: 100mvp-p

6A 8a 72w 96w Desktop Power Supply , Ac To Dc Power Adapter Vi Efficiency

6A 8a 72w 96w Desktop Power Supply , Ac To Dc Power Adapter Vi Efficiency6A 8a 72w 96w Desktop Power Supply , Ac To Dc Power Adapter Vi Efficiency
